Operating Instructions
34
TRANSAXLE LOCKOUT
IMPORTANT: DO NOT TOW this mower faster than
2 mph (3.2 km/h) with the transmission lockout en-
gaged. Towing can produce excessive internal
pressure and damage the transaxle(s).
To move the mower with the engine NOT running
(dead battery, maintenance, etc.), the transaxles
need to be unlocked (released).
1. Raise the body.
2. Pull up on each transaxle lockout arm and move
toward the center of the machine to engage the
step that holds the arm in the UP (unlocked)
position.
3. The mower will “freewheel” with the arms in the
LOCKOUT position. The levers must be in the
highest position to completely unlock the trans-
missions.
Hydro Lockout Arm
Hydro Lockout Arm - Freewheel Position
4. After moving the mower, release the arms,
placing them down in the normal OPERATING
position. The transmission arm ends should be
completely retracted against the chassis,
otherwise operation of the transmission may be
erratic.
Hydro Lockout Arm
Hydro Lockout Arm - Normal Operating Position
