Operating Instructions
36
• When operating on a slope, reduce speed and
use caution to start, stop, and maneuver. Avoid
sharp turns or sudden changes in direction. The
maximum recommended slope operating angle
is 15 degrees or 26% grade.
8600-9
60 lb·ft (81 N· m)
8600-14
16 in.
15°
52 in.
Maximum
Recommended
Slope -
Do Not Operate
on Steep Slopes
Maximum Recommended Slope
DANGER
Do not mow or drive the tractor within 5 feet
(1.5 meters) of an embankment or retaining
wall with drop off.
RECOMMENDATIONS FOR TILT-UP DECK
OPERATION/TRANSPORT
To avoid potential deck and/or tractor damage while
using the tilt-up deck, the following recommenda-
tions are offered:
• Do not move the tractor with the deck in the tilt-
up position since both the roller wheels (on the back
of the deck) may be damaged by moving the tractor.
The tilt-up configuration should only be used when
the tractor is parked.
• The tractor body should never be tilted for-
ward with the deck in the tilt-up position. This can
cause the deck to unhook from the tractor and fall
with considerable force, potentially causing deck or
tractor damage and/or bodily injury.
• When transporting a tractor with the deck in the
tilt-up position (on a truck or trailer), the deck should
be secured to the vehicle with a strap or rope (stop
vertical movement). This will prevent the deck from
bouncing on the rear roller wheels (causing break-
age). This will also prevent the deck from unhooking
from the tractor and falling, potentially causing deck
or tractor damage. Damage to other items parked
in front of the deck may also occur.
No Driving Zone
