B23 Safety Instructions

SAFETY, CONTROL, AND INSTRUCTION DECALS

Safety, Control, and Instruction Decals are installed on the machine;

if any are missing, illegible, or damaged, a replacement should be ordered and installed before

putting the machine into operation. The Decal Part Number is listed below and in the Parts Manual.

Location: Deck Gearbox Cover

Part Number: 8600-39

Warning - stop engine and remove ignition key

before adjusting deck cutting height.

8600-9

60 lb·ft (81 N·m)

Location: Gearbox Cover

(Gear-Driven Decks Only)

Part Number: 8600-9

Tighten blade nuts on gear-driven decks to

60 lb·ft (81 N·m).

8600 -12

Location: Underside of Rear Body, Behind Seat

Part Number: 8600-12

Warning – carbon monoxide (CO) poisoning

hazard.

● CO emitted by a running engine can be deadly.

● Do not operate indoors or in other enclosed

areas.

Location: Frame Crossmember Above Engine

Part Number: 5855

Location: Underside of Seat Panel

Part Number: 4107-13

1. Ground drive belt routing.

2. Engine/PTO belt routing.

8600-5

Location: Rear Body Near Mu󰀪er

Part Number: 8600-5

Warning – hot surface, do not touch.
