Walker H37i - Component Identification

Component Identication
6
Front View and Right Side View
NOTE: Control Identication
shown in Operating
Instructions section.
Body TiltUp
Latch
Deck Height
Lift Chain
Deck
TiltUp Bar
Deck Support Arm
(Not Visible)
Adjustable
Footrests
Forward Speed
Control (FSC)
Friction
Adjustment
Deck Lift Foot Pedal
(Raises Deck)
Cutting Height Release Lever
(Cutting Height Adjustment)
Deck Support Arm
TiltUp Latch
Deck TiltUp
Socket
TiltUp
Hook
Deck
Caster Wheels
Counterweight Springs and
Protective Covers
