52
Maintenance Instructions LUBRICATION
Ident Lubrication No.
No. Location Type Places
Ident Lubrication No.
No. Location Type Places
1 Deck Caster Wheel Fork Pivot Grease 2
2 Deck Caster Wheel Bearing Grease 2
3 Front Deck Lift Pivot Grease 2
4 Rear Deck Lift Pivot Grease 2
5 Pivot Assembly, Tilt-Up Deck
Δ
Grease 2
6 Deck Support Arm Socket Grease 2
7 Steering Lever Pivot Grease 2
8 Deck Support Arm Pivot Grease 2
9 Deck-to-PTO Coupling Grease 1
(Grease Spline Slide Area)
10 Universal Joint Tube Assembly Grease* 1
11 FSC Lever Pivot Grease 1
12 Hydro Idler Arm Pivot Grease 1
13 Body Latch Pivot Oil 2
14 PTO Clutch Lever Pivot Grease 1
15 Clutch Arm Pivot Grease 1
16 Transaxle Oil Reservoir Oil/20W-50** 1
17 Throttle Control Cable Ends Oil 2
18 Tail Wheel Caster Fork Pivot Grease 2
19 Rear Axle Pivot Grease 1
20 Rear Wheel Bearing Grease 2
21 Engine Dipstick Oil** 1
22 Engine Oil Fill Oil** 1
23 PTO Belt Tightener Pivot Grease 1
24 Clutch Actuator Push Rod Grease 1
25 Brake Band Pivot Pins (Clevis) Oil 2
26 Parking Brake Pivot Grease 1
27 Parking Brake Clevis Oil 3
28 Throttle Control Pivot Oil 1
29 Universal Joint Shaft Assembly Grease* 1
30 Blade Spindle
Δ
Grease 3
* Greaseeverytwenty-ve(25)hours.
** Refer to Engine Oil located on page 48 and Check
Transaxle Fluid Levellocatedonpage50.
Δ Fitting located underside, access with deck in tilt-up
position.
NOTE: DR64Tilt-UpDeckisshownforreference.Forother
Deck Lubrication Points, Refer to Deck and Carrier
Frame Illustrated Parts Manual.
