Maintenance Instructions LUBRICATION
Ident Lubrication No.
No. Location Type Places
Ident Lubrication No.
No. Location Type Places
1 Deck Caster Wheel Fork Pivot Grease 2
2 Deck Caster Wheel Bearing Grease 2
3 Front Deck Lift Pivot Grease 2
4 Rear Deck Lift Pivot Grease 2
5 Pivot Assembly, Tilt-Up Deck Grease 2
6 Deck Support Arm Socket Grease 2
7 Steering Lever Pivot Grease 2
8 Deck-to-PTO Coupling Grease 1
(Grease Spline Slide Area)
9 Deck Support Arm Pivot Grease 2
10 Universal Joint Tube Assembly Grease* 1
11 FSC Lever Pivot Grease 1
12 Hydro Idler Arm Pivot Grease 1
13 Clutch Actuator Push Rod Grease 1
14 Body Latch Pivot Oil 2
15 PTO Clutch Lever Pivot Grease 1
16 Clutch Arm Pivot Grease 1
17 Transaxle Oil Reservoir Oil 2
18 Throttle Control Cable Ends Oil 2
19 Engine Dipstick Oil** 1
20 Tail Wheel Caster Fork Pivot Grease 2
21 Rear Axle Pivot Grease 1
22 Rear Wheel Bearing Grease 2
23 Engine / Oil Filler Oil** 1
24 PTO Belt Tightener Pivot Grease 1
25 Parking Brake Pivot Grease 1
26 Throttle Control Pivot Oil 1
27 Universal Joint Shaft Assembly Grease* 1
28 Blade Spindles Grease 3
* Grease every eight (8) hours.
** Refer to Engine Oil located on page 42.
NOTE: DRD52 Tilt-Up Deck is shown for reference. For other
Deck Lubrication Points, refer to Deck and Carrier
Frame Illustrated Parts Manual.
