Walker R21 User Manual

R21 General Information
7
Front View and Right Side View
Component Identication
This section identies the main features of the R21. Control features are identied and explained in the sec-
tion “Operator Controls” on page 19.
Deck Lift
Handle
Counterweight
Spring
Deck
Caster Wheels
Tilt Bar
Socket
Deck Tilt Bar
Counterweight
Spring
Oil Dipstick
and Fill
Tilt-Up
Link
Deck Belt
Cover
Tilt-Up
Lock Hole
Footrest Lift
Latch
Side
Discharge
Shield
Drive Belt Cover
FSC
Friction
Adjustment
Carrier
Frame

Walker R21 Specifications

General

Drive System	Hydrostatic
Cutting Height	1.5 - 4.5 inches
Engine	Kohler CH740
Engine Type	Air-cooled
Cutting Width	52 inch
Wheel Size	20 inches (rear)
