EN - V2.0 12
3.1 Master and Slave setup and Powering On
The selection of the rotary switch determines the role in the power sharing system.
INSTALLATION GUIDE
0 Slave
8
or 9 Master
Any
other Normal charger
(see installation manual)
The chargers can be configured in the following way:
• Any combinations are possible
• The master can be set at any position within the group (T or NT).
Charger Master Slave
Copper X x
Commander X X
Pulsar x
