Wallbox Power Sharing - Protection Recommendations

WBPS-IM-001-EN
8/9
6. Protection recommendations
For safety reasons, an RCD (Residual Current Device) and an MCB (Main Circuit Breaker) should be installed.
It should follow the local national low voltage technical requirements.
We recommend for the mains protection consumption:
63A configuration 150A Configuration
RCD (63A, 300mA) RCD (150A, 300mA)
MCB of 63 A. MCB of 150 A.
We recommend to installation for every charger RCD and MCB protections as follow:
Single phase
RCD type A (32 A, 30 mA)
MCB of 40A / 32A.
Three-
phase
RCD type B (32 A, 30 mA)
MCB of 40A / 32A.
If the charger is outside a surge protector should be installed.
Pulsar (Connector P2)
PIN CABLE
PIN 1 none
PIN 2 none
PIN 3 none
PIN 4 CAN_L
PIN 5 CAN_H
Commander (Connector P2)
PIN CABLE
PIN 1
none
PIN 2 none
PIN 3 none
PIN 4 CAN_H
PIN 5 CAN_L
