Wallbox Supernova - Site Space Requirements; Cable Reach

22 23
Site Space Requirements
PRODUCT DESCRIPTION AND SITE PREPARATION
During the installation, make sure to leave a certain minimum
distance from possible objects around it, in order to allow the door
opening and to facilitate possible maintenance operations.
The image below shows the recommended minimum
distance needed to perform the installation.
64 cm
38 cm
38 cm38 cm
Cable Reach
PRODUCT DESCRIPTION AND SITE PREPARATION
Depending on the version purchased, Supernova fast charging station
comes with a 3 m, 5 m or 7 m cable. The following figure shows the
operating radius of the cables for the two outlets of the charger.
3 m
5 m
7 m
