22 | P a g e
Wallgate Thrii®
PRODUCT MANUAL Issue 5_3
ORIGINAL INSTRUCTIONS
© 2013 Wallgate Ltd.
8. Unscrew the cap from the soap container Fig. 17b and replace with the push-fit cap
pre-connected to the soap tube Fig. 17c pushing fully into place ensuring no leaks.
9. Press the soap prime switch, (located at the rear of the engine unit in the window aperture to the
left of the mains connector (see Fig.3), until soap is consistently dispensed into the bowl.
If only rear access is required lock the fascia into the closed position using the front screw fixing
and secure using the fixings provided (see Fig. 11).
10. When ready for use, a green light will emit from the dispensing unit into the wash bowl. Once
hands are placed under the dispensing unit this light will turn to blue and will activate the wash
cycle. The light then changes to red when the hand dryer is operating. Check the wash & dry cycle
operates correctly as per the list of checks below and repeat the cycle at least five times.
Soap dispenses
Water dispenses & water is warm
Hand dryer operates (Note that the dryer operates whilst the hand sensor detects the
presence of hands in the bowl, the dryer will stop when the sensor fails to detect any
hands after a period of 4 seconds.
11. If required by the customer, fit the user instruction label to the dispensing unit as per Fig.1
12. Upon completion ensure that a copy of the instruction manual (or leaflet), the instruction label (if
not fitted) and the fascia lock key are passed to the customer.
