4. Technical Specification
Weight
Item
Fascia
Engine
Support frame, etc.
Full soap container
Total
Solid surface
15.3 kg
7.0 kg
4.5 kg
2.6 kg
29.4 kg
Solid surface
DISABLED
15.3 kg
7.0 kg
4.5 kg
2.6 kg
29.4 kg
Stainless
Steel
7.7 kg
7.0 kg
4.5 kg
2.6 kg
21.8kg
Dimensions
Width
Height
Depth
450mm
870mm
310mm
450mm
793mm
310mm
450mm
870mm
310mm
(250mm behind the panel on all models)
Water Supply
Minimum pressure
Maximum rating
Inlet connection size
Dynamic
1 Bar / 100 kPa
10 Bar / 1000 kPa
15mm Push Fit
(or 1/2” BSP FM adapter)
Electrical Power
requirement
220–240V 50/60Hz, single phase, 2.6 to 3.1 kW
(13 Amp fused double pole switched spur)
Enclosure IP
Rating
IPX4
Regulatory
compliance
Complies with:
RoHS
LVD 2006/95/EC & EMC 2004/108/EC directives.
Solid Surface
Approvals
BS476 Pt 6 Class 0 & 7 Class 1 – fire propagation and surface
spread of flame
ISO EN 19712-3-2007 rated 5 for durability, stain resistance,
cigarette burns, etc.
Water heater
Water temperature range
Factory set @ 38°C
*Based on 12°C supply temperature, 3Bar dynamic
pressure & 230V supply.
30°C to 45°C
Flow rate of 1.5LPM*
Water
Resistivity
Water resistivity must not be less than 1300 Ωcm
(refer EN603355-2)
AS 3498
Certificate No 23167
