10 | P a g e
Wallgate Thrii®
PRODUCT MANUAL Issue 5_3
ORIGINAL INSTRUCTIONS
© 2013 Wallgate Ltd.
6. Installation and Commissioning
The Wallgate Thrii handwash-drier unit is a three-part assemblyconsisting of a flush support frame
and a hinged fascia and engine assembly. It is necessary to install the mounting frame and
prepare the services (electrical, water and waste) prior to installing the fascia.
It is important that when selecting a mounting position consideration be given to the suitability
of the wall construction, so that it is able to bear the weight of the assembled unit in both the
open and closed positions, and able to withstand the clamping method as shown in Fig.6
6.1 Package Contents
Before you begin the installation, make sure that you have the following items:
1 Support frame
1 Installation instructions
1 Wall frame waste connector
1 Waste pipe 32 – 40mm adapter pipe
1 Fascia lock key
1 Mains electrical plug and lead (2 metre length)
1 User instruction label
1 Set of mounting brackets and fixings
1 Fascia
1 Engine
1 Container of liquid soap (2.5 litre)
6.2 Site Preparation
6.2.1 Mounting guidelines
Looking at the front of the unit the fascia hinges are on the right-hand side. For front access
allow for the left-hand edge of fascia to swing out (120°) to allow full internal access.
Water, mains power andwaste water connections are located on the hinged side of the unit.
