7.1 Operation
The hand wash & dry cycle is activated when your hands are placed centrally into the wash bowl
below the dispensing nozzles. An infra-red hand sensor initiates the cycle when it detects hands in
the bowl area. When the cycle starts, a sequence of soap, warm water & hand dryer air are
dispensed. Note that the hand dryer will cease to operate shortly after hands have been removed
from the wash bowl or the pre-set dryer cycle time has been reached.
7.1.1 Soap Operation
There are 2 settings for soap delivery, LIQUID (default) or FOAM. The controls to set the required
soap option are located on engine unit. To change the settings the unit must be powered up.
There are 2 controls that need to be altered:
1. At the window to the left of the mains connector there is a small push button labelled ‘Soap’.
Press and hold this button to select the desired setting this will be confirmed by an illuminated
LED see Fig.18
2. Adjust the soap selection knob see Fig.2 item 23
Ensure that both button setting and soap selection knob position select the same operation.
Failure to do so may result in an incorrect operation.
Low soap level indicator:
A function on the unit can be enabled, to indicate that the soap container level is low. When this
function is set to ON (Default setting is OFF) & the soap is at a low level the bowl light will pulse
once per second. To turn ON this function refer to section 7.2 for “Advanced Adjustments” and
select menu item F146 which is the setting for number of soap operations before the warning
light is activated. Setting this to 20 will activate the warning light after 2000 operations. The
setting may require adjustment if the number of operations per full soap container is found to be
fewer or greater than the setting.
To reset the warning light there are two options.
1. Press buttons 2 & 3 on the display together & hold for 5 seconds.
2. The reset can be done when the soap prime push button is activated but this option has
to be enabled by setting menu item F148 to 1. Refer to section 7.2 for “Advanced
Adjustments”.
7.1.2 Dryer Operation
There are 3 dryer speed settings. The control to adjust the speed is located at the rear of the unit.
To change the speed the unit must be powered up (The fan does not need to be operating). On
the LCD Control there is a small push button labelled ‘Fan Speed’ see Fig.18. Press and hold this
