Product Manual WDC200 Electronic Control
Revision 18
9.3. WDC200-3
The WD200-3 is a standard WDC200 with eight setting changes to allow it to operate
a PSHD23. The PSHD23 is an extremely safe in-cell hand wash solution used in
police holding cells, refer to Wallgate website for details (www.wallgate.com). The
settings refer to the water run time on the unit. The setting changes are in “CELL 1
WATER SETTINGS” and “CELL 2 WATER SETTINGS” menus and are as follows:
Menu setting:
WDC200-3 Setting:
BASIN HOT CYCLE
6 SECONDS
BASIN CYCLE ACTIVATIONS
1
BASIN CYCLE PERIOD
15 MINUTES
BASIN LOCKOUT TIME
15 MINUTES
Menu setting:
WDC200-3 Setting:
SHOWER CYCLE:
5 SECONDS
SHOWER CYCLE ACTIVATIONS
3
SHOWER CYCLE PERIOD
15 MINUTES
SHOWER LOCKOUT TIME
15 MINUTES
