Walther MPP-03-PRO - Spare Part List

Rev. 1.6
Assembly Instructions - Micro Point Pulse Valve MPP-03-PRO
Page 16 of 22
Walther Systemtechnik GmbH – D 76726 Germersheim
Telefon: +49 (0)7274-7022-0 Telefax: +49 (0)7274-7022-91
http://www.walther-2000.de – info@walther-2000.de
10.1.2 Spare Part List
Pos.
Article No.
Qty
Description
1.0
*
1
Nozzle full-jet (adhesives/KLS)
3.0
97511051
1
Main body, complete
4.0
97220089
1
Screw joint, complete, SW 8 x 19mm
5.0
97640102
1
Material gasket set
5.1
97640004
1
Variseal
5.2
97640021
1
O-Ring / Viton®
6.0
97810014
1
Sealing screw, complete, 11 x 21mm, Viton®
6.1
97810013
1
Sealing screw, diam. 11 x 21mm
6.2
97640026
1
O-Ring / Viton®
7.0
979866.01
1
Nozzle needle standard, complete (incl. Piston of stainless and Quad-
ring 7.1)
979866.02
1
Carbide-nozzle needle 0,3, complete (incl. Piston of stainless and
Quad-ring 7.1)
979866.03
1
Carbide-nozzle needle 0,5, complete (incl. Piston of stainless and
Quad-ring 7.1)
979866.04
1
Carbide-nozzle needle 0,8, complete (incl. Piston of stainless and
Quad-ring 7.1)
7.1
2000128.0000
1
Quad-ring / Viton®
8.0
97820020
97820024
1
1
pressure spring 1.1 x 22mm (0 - 30 bar material pressure), blasting
pressure spring 1.2 x 21.5mm (30 - 100 bar material pressure), blasting
9.0
97900008
1
Raster needle lock
10.0
97150126
1
Solenoid valve 5/2-ways
11.0
97150127
1
Plug-in cable
12.0
97910344
1
Clamp angle, 38 x 20 x 15mm, nickel-plated
1
Standard
* Article numbers can be found on the following pages.
IMPORTANT
Always indicate the inscribed serial numbers when ordering spare parts!
