10.5.4 Orientation towards Valve Body with Installed Nozzle Extension
Line
Characteristics
Contents
A
Total length "GL" [mm]
#
B
Construction length "X" [mm]
#
C
Model DVL – outside Ø [mm]
#
D
Nozzle - Ø [mm]
#
E
Application direction ∟[°]
#
F
Orientation towards valve body ∟[°]
#
G
Pulsing tube
with / without
H
Indexing
with
