VL
3.0 TECHNICAL INFORMATION
2
VAL.130.--.M.EN Issue: A1
09.16
10
VIB Slides Valves are used in all types of bulk solids processing plants where interception of gravity-fed or
conveyed dry powders or granules is required. VIB6OLGH9DOYHVPD\EH¿WWHGEHQHDWKKRSSHUVELQVVLORV
outlet, on inlets and outlets of mechanical conveyors, as well as on the inlet of telescopic loading spouts. Due
to their special design and to the engineering materials used, they represent a particularly economic yet most
HI¿FLHQWVROXWLRQ
VIB Slide Valves consist of two high-pressure die-cast semi-bodies manufactured from aluminium alloy, a slid-
ing blade in carbon or stainless steel, a carbon or stainless steel frame and a pre-stressed elastomeric seal in
WAM’s SINT
®
engineering polymer composite.
The special geometry of new “Slim” VIB Slide Valves and the various options in blade design enable their ap-
plication in virtually all industries including Food processing. For the food industry it is available a version with
stainless steel blade and frame and FOOD approved seal is available.
VIB6OLGH9DOYHVDUHDYDLODEOHLQDYDULHW\RIFRQ¿JXUDWLRQVVIBQ version comes with a square inlet, in the
VIBC version with a circular open cross section. VIBYDOYHVFDQEH¿WWHGZLWKDPDQXDOSQHXPDWLFRUJHDUHG
motor actuator. All actuator systems are interchangeable (see ACTUATOR catalogue).
Important
The terms ³equipment´ and ³valve´ used in this manual refer to the same machine.
As components meant for installation in a plant, the valves - not fully provided with safety means -
have to be considered ³partly completed machinery´. Therefore, they do not bear an EC marking.
It is forbidden to start the valve unless the machine/plant in which it is to be installed has been de-
clared compliant with the Directive 2006/42/EC and further modi¿cations.
3.1 General description of the valve
