3.2 Main components
A) Die cast aluminium semi-bodies
B) Blade
C) SINT
®
liner
D) Roller bearing
E) $FWXDWRU¿[LQJSODWH
F) Back lateral frame
G) Protection plate
A
A
B
C
G
D
E
F
D
G
