10.0 TECHNICAL DATA
VL
2
VAL.130.--.M.EN Issue: A1
09.16
51
VIBQ
VIB A B C D E N° E ØF BOLTS G H I kg
150 120 175 261 15.5 115 2 12.5 M10 510 61 125 10
200 170 225 311 15.5 93.3 3 12.5 M10 610 61 122 14
250 220 275 361 15.5 110 3 12.5 M10 710 61 122 17
300 270 325 438 26.5 128.3 3 12.5 M10 840 61 122 24
350 320 375 489 22 89 5 12.5 M10 961 71 145 34
400 370 425 531 20 100 5 12.5 M10 1058 71 145 41
