Controls and commands
14
Rear view
Condenser grid
Mains cable guide
Mains plug socket
Serial communication port
Accessory
power socket
Pressure safety valve cover
Detail of the hydraulic connections (optional)
Water supply inlet
Used water drain
The water supply system must deliver demineralized water meeting the
requirements as listed in ANNEX
4
.
Do not add any chemical / additive to the water.
The manufacturer’s warranty is void if the sterilizer was used with water
containing either chemical additives, or contaminant levels exceeding
those listed in ANNEX
4
.
The water supply system must be fitted with a backflow preventing
device complying to IEC 61770 and to national and local regulations.
The maintenance of the external water filling system must be done in
exact accordance with the information of the instructions for use given
with the relevant system.
All the cables and tubes connected on the rear side of the sterilizer must
be placed far from the condenser grid (e.g. using the available guides).
