Wareforce UL30 - UH30-FND Chemical Feeder Pumps

36
07610-004-37-37-P
UH30-FND CHEMICAL FEEDER PUMPS
PARTS
0
57
0
0-
005-00-2
9
10
9
8
1
2
6
7
3
4
5
0
5
7
0
0-
004-71-6
3
11
Machines with serial numbers before
23D415452 have dierent pumps.
Click here to open earlier manual.
NOTICE
ITEM QTY DESCRIPTION PART NUMBER
1 2 Pump Housing 04320-111-37-09
2 4 Screw, 8-32 x 3/8" Phillips 05305-011-37-07
3 1 Roller, Plastic 04320-002-82-28
4 2 Pump Cover 04320-111-37-08
5 8 Screw, 6-32 x 3/4" Phillips 05305-011-37-05
6 4 Screw, 8-32 x 1/2" Phillips 05305-011-37-06
7 1 Tube, Squeeze, 8" 05700-003-22-89
8 1 Motor, 38 RPM 04320-004-99-36
9 1 Roller, Plastic 04320-111-65-27
10 1 Tube, Squeeze, 9" 05700-011-65-21
11 1 Motor, 14 RPM 04320-011-63-33
