Wareforce UL30 - UL30 Chemical Feeder Pump Assembly

07610-004-37-37-P
37
ITEM QTY DESCRIPTION PART NUMBER
1 1 Complete Peri-pump Assembly, 14 RPM* 05700-004-71-61
2 2 Complete Peri-pump Assembly, 36 RPM* 05700-004-71-60
3 1 Tubing, White, 1/4" x 48" 05700-002-62-13
4 1 Tubing, Blue, 1/4" x 48" 05700-002-62-11
5 1 Tubing, Red, 1/4" x 48" 05700-002-62-12
6 1 Tubing, White, 1/4" x 100" 05700-003-20-67
7 1 Tubing, Blue, 1/4" x 100" 05700-003-20-68
8 1 Tubing, Red, 1/4" x 100" 05700-003-03-45
9 1 Track Mount Assembly 05700-004-37-94
10 1 Peri-pump Channel 05700-003-53-25
UL30 CHEMICAL FEEDER ASSEMBLY
PARTS
1
2
6
7
8
2
3
5
4
10
9
*Components on next page.
