Wareforce UL30 - Electrical Requirements

4
07610-004-37-37-P
All electrical ratings provided in this manual are for reference
only. Always refer to the machine data plate to get exact electrical
information for this machine. All electrical work performed on
machines should be done in accordance with applicable
local, state, territorial, and national codes. Work should only
be performed by qualied electricians and authorized service
agents.
The electrical congurations of this series of machines are as
follows:
Available Electrical Characteristics:
UH30-FND
• 208 V, 60 Hz, Single-phase
• 230 V, 60 Hz, Single-phase
UL30
• 115 V, 60 Hz, Single-phase
Available Wash Tank Heater:
• 1.5 kW (UL30 Only)
*Motor and heater do not operate at same time. Total load based
on motor load.
VOLTS 208 230
PHASE 1 1
FREQ 60 60
WASH
MOTOR
AMPS
5.0 A 5.0 A
RINSE
HEATER
AMPS
32.2 A 35.7 A
TOTAL
LOAD
37.2 A 40.7 A
NOTICE
i
ELECTRICAL REQUIREMENTS
SPECIFICATIONS
UH30-FND
UL30
VOLTS 115
PHASE 1
FREQ 60
WASH
MOTOR
AMPS
10.0 A
WASH
HEATER
AMPS
13.0 A
TOTAL
LOAD
10.0 A*
Electrical Characteristics
