42
07610-004-37-37-P
Use teon tape on threads. Do NOT use "pipe dope."
ITEM QTY DESCRIPTION PART NUMBER
1 1 Vacuum Breaker 04820-003-06-13
2 1 Elbow, 1/2" NPT x 3/4" Hose, 45-Degree 04730-003-29-22
3 1 Pipe Clamp 05700-011-38-62
4 2 Pipe Clamp (Side of Unit) 05700-000-35-05
5 1 Hose Union, 1/2" 04720-004-24-68
6 1 Male Adapter 04730-401-03-01
7 2 Elbow, 1/2" 04730-406-31-01
8 1 Copper Pipe, 1/2" x 1 3/8" 05700-004-69-44
9 1 Valve, 1/2" 04810-003-71-55
10 1 Copper Pipe, 1/2" x 6 1/2" 05700-002-60-71
11 1 Copper Pipe, 1/2" x 5 1/4" 05700-002-04-92
12 1 Elbow, 1/2", 45-Degree 04730-011-67-77
13 1 Copper Pipe, 1/2" x 25 1/2" 05700-011-59-85
14 1 Male Adapter 04730-011-59-53
15 1 Upper Manifold 05700-031-34-82
16 2 Rinse Plumbing Plate 05700-011-82-86
17 1 Rinse Plumbing Gasket 05330-111-42-81
18 1 Manifold 05700-002-13-75
19 1 Manifold Tube Position Bracket 05700-011-34-63
20 1 Lower Manifold 05700-021-52-80
21 1 O-ring 05330-002-60-69
22 1 Deector Plate 05700-002-62-49
NOTICE
UL30 PLUMBING
PARTS
