SETTING YOUR HEATING SYSTEM
Floor type
This setting will affect the upper and lower limits of
programmable set temperatures as well as the overheat limit.
If you set a user defined limit then you are advised to check
the safe temperature limits with the flooring manufacturer
Master/ relay
This feature allows you to use one thermostat to control
another. This is useful if you need to control multiple floor
heating elements with one program. In order to set-up this
feature use the following steps:
1. Choose which thermostat will be the “master” and
which will be the “relay”.
2. Use low voltage electric cable to connect terminal 3 on
the “master” to terminal 3 on the “relay”.
3. Use low voltage electric cable to connect terminal 2 on
the “master” to terminal 2 on the “relay”.
4. In advanced settings of each thermostat switch the
“master” thermostat to master mode and the “relay”
thermostat to relay mode.
5. Program desired schedule into the “master”
thermostat. The “relay” thermostat will no longer use
its sensors for thermal regulation. It will now turn on/
off in tandem with the “master” thermostat.
LOn the “master” thermostat these connector cables
are in addition to the floor sensor but on the “relay”
thermostat the floor sensor is not necessary.
