Warn 101255 - Caution: Moving Parts Entanglement Hazard; Notice: Equipment Damage; Tools and Specifications; Tools Required

To Next Page

To Previous Page

CAUTION

MOVING PARTS ENTANGLEMENT HAZARD

Failure to observe these instructions could lead to minor or moderate injury

• Always take time to fully read and understand the installation and Operations Guide included with this product.

• Never operate this product if you are under 16 years of age.

• Never operate this product when under the inuence of drugs, alcohol or medications.

Read installation and operating instructions thoroughly.

TABLE OF CONTENTS

Tools Required ............................................................................................................................. page 2

Torque Specications ................................................................................................................page 2

Parts List.........................................................................................................................................page 3

Installation ............................................................................................................................. page 4-11

Maintenance/Care ................................................................................................................... page 11

TOOLS REQUIRED

- Standard wrenches

- Standard sockets

- Hacksaw Blade with Handle (ne tooth)

NOTICE

EQUIPMENT DAMAGE

• Never tow vehicle by attaching a tow bar to the eyelets on the bumper.

• Never attach tow bars directly to the bumper. Damage to bumper may occur. WARN bumpers are not designed to be used for at towing. Consult with the manufacturer of your tow bar system for the proper vehicle tow

bar brackets..

Read installation and operating instructions thoroughly.

TORQUE SPECIFICATIONS

Please use the recommended torque specications when assembling this product unless otherwise specied in the instructions.

FASTENER SIZE FASTENER TORQUE FASTENER SIZE FASTENER TORQUE

lb-ft (N.m) lb-ft (N.m)

1/4" 8 (11) M4 (2) 3

5/16" 17 (23) M5 (4.5) 6

3/8" 30 (40) M6 (7.5) 10

7/16” 48 (66) M8 (18) 25

1/2" 74 (100) M10 (37) 50

9/16” 106 (144)
