Warn 101255 - Parts List; Component Identification

©2021 Warn Industries, Inc. WARN® and the WARN logo are trademarks of Warn Industries Inc. 3 100243A1
PARTS LIST
ID No. PART NO. QTY Description
A1 101251 1 WINCH PLATE
A2 101304 1 LH WINCH PLATE BRACKET
A3 101303 1 RH WINCH PLATE BRACKET
A4 101305 2 WINCH PLATE SPACER
A5 101256 1 FILLER PLATE
B1 81707 4 M10 X 1.5 X 40 CARRIAGE BOLT
B2 87166 4 M10 X 1.5 FLANGE ELASTIC NUT
B3 79146 5 M8 X 1.25 HEX FLANGE NUT (not shown)
A1
A2
A3
A4
A4
A5
B2
B1
