Warn 106413 - Caution: Moving Parts Entanglement Hazard; Notice: Equipment Damage; Before You Begin; Interference with Driver Assist Systems

©2019 Warn Industries, Inc. WARN® and the WARN logo are trademarks of Warn Industries Inc. 2 106532A1
Tools Required .................................................................. page 2
Parts List .............................................................................. page 3
Torque Specications ..................................................... page 3
Installation ......................................................................page 4-9
Maintenance/Care ........................................................... page 10
EQUIPMENT DAMAGE
• Never tow vehicle by attaching a tow bar to the eyelets on the bumper.
• Do not attach tow bars directly to the bumper. Damage to bumper may occur. WARN bumpers are not designed to be used for at towing. Consult with the
manufacturer of your tow bar system for the proper vehicle tow bar brackets..
Read installation and operating instructions thoroughly.
MOVING PARTS ENTANGLEMENT HAZARD
Failure to observe these instructions could lead to minor or moderate injury
• Part edges may be sharp!
• Always use proper posture / lifting technique or get lifting assistance while handling and installing product.
Read installation and operating instructions thoroughly.
This product may interfere with driver assist systems such as adaptive cruise control and parking assist
systems that have sensors or cameras installed in the bumpers or front grill area. If your vehicle is
equipped with any of these systems or features, consult your vehicle owner’s manual before installing this
product. These systems may need to be disabled as a result of installing this product.
NOTICE
CAUTION
NOTES
BEFORE YOU BEGIN
TABLE OF CONTENTS
• 8mm Hex Key
• 17mm Wrench
• 10mm Socket and
Ratchet
• 12mm , 13mm Socket
• Socket Extension
TOOLS REQUIRED
• Philips Head Screwdriver
• Small Flat Head Screwdriver or body panel tool
• Ring Terminal
• Cutting tool
• Installation is shown with Axon 55-S winch.
• Installation will vary slightly with steel rope due to fairlead dierences
• Light Bar can be installed in place of winch using slots on winch surface or on internal gussets.
