PAGE 3 85553 Rev. A0
Installing the Winch to the Portable Anchor Plate
Installation of Winch
Identify the whole pattern for your winch. Install the winch per your application using the hardware included
in the winch. Refer to the winch user manual for specific winch installation information.
For the 4700 and early utlity winches
that did not have the integrated
fairlead, it will be necessary to use
the fairlead plate provided with the
winch.
Simply sandwich the fairlead plate
between the winch and the Portable
Anchor Plate.
