WARN® INDUSTRIES PAGE 7 72171 Rev A0
6. Slide the brace down through the trimmed
opening. See Figure 9. Locate the top of the
brace along the outer side of the frame member.
See Figure 10 and 11.
Figure 9 Installation of brace, LHS shown.
Figure 10 Locate top of brace to outside of upper frame tube.
Figure 11 Lower holes of brace fasten to mounting bracket.
Brace
Vehicle Storage Tray
Frame Member
