WARN INDUSTRIES PAGE 3 84856A0
II. Tools Required
• Ratchet
• Sockets: 10mm, 12mm, 7/16”, 1/2”, 9/16”
• Wrenches: 1/2”, 9/16”
• Drill
• 1/4” drill bit
I. Parts List
Ref Description Qty
A1 Mounting Plate 1
B1 1/4-20 x 1” x 1 1/2” U-bolt 2
B2 1/4” at washer 4
B3 1/4-20 lock nut 4
B4 8mm-1.25 x 25mm bolt 2
B5 Spacer 2
