Warn 84705 - Winch Wiring

WARN INDUSTRIES PAGE 9 84856A0
IV. Winch Wiring
Please refer to the Installation and Specication
Guide, supplied in the winch kit, for all wiring
schematics and specic details on how to wire
the winch to the ATV.
Notice
Figure15UniversalWiringInstallationdiagram
Blue
(6 ga.)
Red
(20 ga.)
Black
(6 ga.)
Green
Black
Red
(6 ga.)
(Remote optional for
2.5ci)
Yellow
(6 ga.)
