©2015 Warn Industries, Inc.WARN® and the WARN logo are trademarks of Warn Industries Inc. 5 95162A1
INSTALLATION INSTRUCTIONS
4. Install the front plow mount bracket using two 5/16” bolts
and washers provided in kit. Do not tighten at this time.
5. Install two M6 u-bolts with four M6 lock nuts provided in
hardware kit. Do not tighten at this time.
6. Remove the zip tie fastening wire harness to the vehicle
frame.
Figure 4
Figure 5
Figure 6
Front Plow
Mount
To Next Page
