10. Reinstall lower front plastic re-using the torx screws removed
in step 1.
NOTE: You may need to trim the lower front plastic for
clearance of plow mount and arms.
11. Attach left and right puck ange to the plow push tube
assembly as shown. Flanges should be mounted internally
with pucks facing inward.
12. Install two M6 socket head bolts to front plow mount as
shown.
Figure 10
Figure 11
Figure 12
