18.1.2 V-engine
Fig 18-2 Engine room arrangement, V-engine (DAAE075829B)
Min. crankshaft distances [dimensions in mm]
C
1)
B
1)
ATC typeEngine type
11200110005600TPL 71C12V46F
12700113005900TPL 76C14V46F
13700113005900TPL 76C16V46F
1)
Indicative dimension.
18-2 DAAB605814
