Installation
9
15
1833
16
1140
17
1834
Drain connection
Connect a 3" (75 mm) flexible hose to the drain
outlet of the machine.
The drain hose must not have sharp bends and
must slope from the machine to assure proper
drainage.
If the machine drains into an open trough, the
trough should have a minimum slope of 1/8-inch
to 1/4-inch per foot towards the main drain.
Do not reduce the size of the drain connection
from the machine to the waste line.
NOTE
To simplify installation, Wascomat has
made available the following hose kits:
For S28/125 – part. No. 002008
For S28/185 – part. No. 002009
These kits contain inlet hoses, drain hose,
hose clamps and washers.
Start-up and safety checklist
Before initial start-up of a Wascomat washer-
extractor, the following safety checks must be
performed:
• Make sure the machine is properly bolted to
the floor.
• Make sure that all electrical and plumbing
connections have been made in accordance
with applicable local codes.
• Use only flexible water fill and drain hoses of
the proper length to avoid sags and kinks.
• Make sure the machine is properly grounded
electrically.
Fig.
16
Fig.
17
Fig.
15
