WATER ACE PUMP COMPANY

|

1101 MYERS PARKWAY

|

ASHLAND, OHIO 44805-1969 (USA ONLY)

CONSUMER HOT-LINE: 1-800-942-3343

Monday–Friday 7 AM to 5 PM EST

www.waterace.com

INSTALLATION MANUAL Pgs. 1–4

SUBMERSIBLE SUMP PUMPS

POMPES DE PUISARD SUBMERSIBLES

MANUEL D’INSTALLATION Pgs. 5–8

MANUAL DE INSTALACIÓN Pgs. 9-13

BOMBAS DE SUMIDERO SUMERGIBLES

23833A115 (1/19/06)

MODEL

R5V

1/2 HP

MODEL

R3S

1/3 HP

MODEL

R3V

1/3 HP

MODEL

R2SA

1/4 HP

MODEL

R5S-1

1/2 HP

Table of Contents

Questions and Answers

N
Nicole PinedaAug 8, 2025
Why does the fuse blow or circuit breaker trip when my Water Ace Water Pump starts?
- G
  Gregory DawsonAug 8, 2025
  If your Water Ace Water Pump's fuse blows or the circuit breaker trips when the pump starts, it could be due to several reasons. The pump impeller might be partially clogged with tar or paint, causing the motor to run slowly and overload. Alternatively, the fuse or circuit breaker might be too small; it should be 15 amps. Also, check if the impeller or volute openings are clogged and need cleaning.
H
hughesmarkAug 12, 2025
What to do if my Water Ace R5S-1 Water Pump runs but doesn't pump water?
- T
  tanya91Aug 12, 2025
  If your Water Ace Water Pump runs but does not deliver water, several issues could be the cause. First, ensure the check valve is installed correctly, with the arrow pointing in the direction of flow. Also, check that the discharge shutoff valve is open, if one is being used. The pump might be air-locked; try starting and stopping it several times by plugging and unplugging the cord. Inspect the pump case for a clogged vent hole, and examine the impeller or volute openings, as well as the inlet holes in the pump base, for any clogs that need cleaning. Lastly, consider whether the vertical pumping distance is too high, requiring a reduction in distance or a resizing of the pump.
K
Katherine WardAug 17, 2025
How to troubleshoot a Water Ace R5S-1 Water Pump that does not run?
- M
  Melissa WallaceAug 17, 2025
  If your Water Ace Water Pump does not run or hums, there are several potential causes. First, check the line circuit breaker and replace the fuse if necessary. Ensure the water level in the sump has reached the correct turn-on level as indicated in the installation drawing. Verify that the pump cord is making proper contact in the receptacle. Also, make sure the float operates freely in the basin. If all of these are okay, the motor winding may be open.
M
Marcus JohnsonAug 22, 2025
Why does my Water Ace R5S-1 Water Pump keep running and not stop?
- D
  Drew RussellAug 22, 2025
  If your Water Ace Water Pump runs and pumps out the sump but doesn't stop, the float may be stuck in the up position. Ensure the float operates freely in the basin. Also, consider replacing the float switch (RSMA) for R2SA, R3S and R5S-1, or replacing it with a vertical switch RVS for R3V and R5V.
E
Elizabeth EspinozaAug 27, 2025
Why is my Water Ace Water Pump delivering only a small amount of water?
- N
  Nicole SmithAug 27, 2025
  If your Water Ace Water Pump runs but delivers only a small amount of water, it could be due to the pump being air-locked; try starting and stopping it several times by plugging and unplugging the cord. The vertical pumping distance might be too high, so consider reducing the distance or resizing the pump. Also, check for clogged inlet holes in the pump base, or clogged impeller or volute openings. The pump impeller might also be partially clogged with tar or paint, causing the motor to run slowly and overload; in any of these cases, you should remove the pump and clean it.
C
Carol MasonSep 1, 2025
Why does my Water Ace Water Pump motor run for a short time, then stop?
- M
  Margaret Patterson MDSep 1, 2025
  If your Water Ace Water Pump motor runs for a short time, then stops, it could be due to several reasons. The inlet holes in the pump base may be clogged, or the pump impeller may be partially clogged with tar or paint, causing the motor to run slowly and overload. Also, the impeller or volute openings might be fully or partially clogged. In any of these cases, remove the pump and clean the openings. Additionally, the motor stator may be defective.

Summary

Installation Manual Submersible Sump Pumps

Important Instructions Before Installation

Crucial safety warnings and prerequisites before installing the pump to prevent injury or damage.

Sump Pump Installation Procedure

Step-by-step guide for installing the sump pump, including necessary materials and tools.

Complete Pump Installation and Performance

Detailed installation overview, performance table, and diagram for various pump models.

Troubleshooting Checklist

Pump Problem Diagnosis

Lists common pump problems and their potential causes for effective troubleshooting.

Limited Warranty Information

Water Ace Pump Warranty Terms

Details warranty period, exceptions, general terms, and conditions for Water Ace products.

Water Ace R5S-1 Specifications

General

Model	R5S-1
Category	Water Pump
Voltage	115V
Phase	1
Horse Power	0.5 HP
Maximum Pumping Height	25 ft
Switch Type	Automatic
Max Head	25 ft
