WL3000 Technical Manual - May 2014
Index
Technical Manual
Welcome to your new Waterlogic machine.
This Technical Manual is to help you get great tasting water cup
after cup by making the most of the product’s features.
Declaration
Waterlogic International Ltd
1. The installation, maintenance and sanitizing procedures must be carried out by persons trained by
Waterlogic International or their approved distributors. Do not remove any panels or covers unless
acceptable in this instruction.
2. When any abnormal case happens, firstly unplug the appliance.
3. This appliance is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given supervision
or instruction concerning the use of the appliance by a person responsible for their safety.
4. Children should be supervised to ensure that they do not play with the appliance.
5. This appliance can be used by children aged from 8 years and above if they have been given
supervision or instruction concerning use of the appliance in a safe way and if they understand the
hazards involved. Cleaning and user maintenance shall not be made by children unless they are older
than 8 and supervised. Keep the appliance and its power cord out of reach of children aged less than
8 years.
6. Appliances can be used by persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
7. Children must not play with the appliance.
8. If the supply cord or the detachable cord sets are damaged, it must be replaced by the manufacturer,
its service agent or a similarly qualified person in order to avoid a hazard.
9. The detachable hose-sets and the connection kit used to connect the main water are supplied by
the technician. Don’t reuse the old ones.
10. The appliance is to be supplied through a residual current device (RCD) having a rated residual
operating current not exceeding 30mA.
11. This appliance is intended to be used in household and similar applications such as
- staff kitchen areas in shops, offices and other working environments;
- farm houses and by clients in hotels, motels and other residential type environments;
- bed and breakfast type environments;
- catering and similar non-retail applications.
12. This appliance contains a UV-C emitter (UV lamp)
13. Unintended use of the appliance or damage to the housing may result in the escape of dangerous
UV-C radiation. UV-C radiation may, even in little doses, cause harm to the eyes and skin.
14. Appliances that are obviously damaged must not be used.
15. T h e re p lace men t o f th e U V la mp mu st b e ca r rie d o ut b y p ers onne l tr aine d by Wa terl ogic I nter nat i ona l
or their approved distributors.
16. Read the maintenance instructions before opening the appliance.
17. The appliance must be disconnected from the power supply before replacing the UV lamp.
18. The UV lamp must be replaced at 6 month intervals or when necessary. If the unit is placed
in a high use area, the UV lamp will need to be replaced more frequently.
The quartz spiral can be cleaned by using an ultrasonic bath if needed.
19. WARNING: Do not operate the UV lamp when it is removed from the appliance enclosure.
Machine Overview 4
Mains Parts Layout 8
Pre Delivery Inspection Procedures (PDI) 13
Installation Procedures 14
Instructions on Changing the CO2 Bottle 16
Installation Kit 17
Operational Instructions 18
Programming Instructions 22
Menu Options 24
Maintenance and Servicing 26
Sanitising the Machine 28
Descaling a Waterlogic Machine 29
Troubleshooting 30
Technical Specification 31
Environmental Information 32
End of Life 33
Biocote 33
How Carbonated Water is Created 34
Electrical Wiring Diagram and Main PCB Schematic Diagram 36
Wetted Parts Diagrams 46
Main Parts List (Models WLMHC3000/WLMCW3000) 56
