WaterLogic WL7 FIREWALL - Front and Rear View

7
ENG2152-22/05/19
Ergonomic dispensing area with 273 mm able to fill sport bottle.
Child safeguard to prevent accidental dispense of hot water.
Leak prevention system provides extra protection and reduces risks of accidents.
Provides cold water for more than 50 users.
Advanced LCD Screen with auxiliary messaging.
ADDITIONAL FEATURES
5. FRONT AND REAR VIEW
No Description
1 UI display
2 UI dial
3 Waterfall light diuser
4 Drip tray grill
5 Drip tray
6 Handle
No Description
7 1/4” Water inlet connector
8 Power connector
9 Red power switch
10 Green heater/compressor switch
11 1/4” CO
2
inlet connector
12 Condenser
1
2
6
3
12
11
10
8
7
9
4
5
FRONT AND REAR VIEW
