30
IOM-S-Leak Defense 2211 2022-03-15 © 2022 Sentinel Hydrosolutions, LLC
Figure 12
Connecting Water Softener (clack) to
API (Standby trigger)
POWER STANDBY HOME/AWAY
POLD GND V+ IN- IN+ -REF IN- IN+ +REF NCCOMNO NO COM NC
ALARM ALARM
RELAY
#2
RELAY
#1
9-12VDC
5.5 x 2.1mm
LED
TEST PB
MODE SEL
DC MOTOR
RLY1
+COM
CLACK VALVE
RED
BLACK
BLACK
RED
JUMPER
