Call 800.879.8585 for Technical Support
WIRING DIRECTIONS
CAUTION
TURN POWER OFF AT THE CIRCUIT BREAKER
BEFORE INSTALLING SENSORS.
Single Sensor, Single Load
WARNING: This application does not allow for Load to increase.
Load
Switch
Load Hot
Neutral
Neutral
Ground
(Optional)
Hot
Neutral
Neutral
Load
Load
Load
Line
Neutral
Line
Ground
(Optional)
Ground
(Optional)
Strip Gauge
#12 to #16 AWG
Cu Wire Only
Multiple Sensors Connected in Parallel
