Barcode Scanner Module User Manual

12 / 57 Rev1.0 Date:180621

1. Baud rate Setting

USB COMMUNICATION

1. USB PC Keyboard

When you connect the module with USB cable, you can set the module to

keyboard input mode by scanning this code.

2. USB Virtual Port

1200bps

4800bps

*9600bps

14400bps

19600bps

38400bps

57600bps

115200bps

USB PC Keyboard
