Waveshare Barcode Scanner Module User Manual

Barcode Scanner Module User Manual
13 / 57 Rev1.0 Date:180621
You can set the module to USB virtual port mode by scanning this code.
SCANNING MODE
1. Manual Mode
Manual Mode is default scanning mode. In this mode, user should press the
button to begin scanning, and it will finish after scanned or button release.
Sleep
In manual mode, module could enter sleep mode if it being idle for some time.
You can scan this code to configure this function.
Default setting is that the module will enter Sleep mode after 30s if module keeps
idle. And you can wake it up by press button, module will restart after waking.
2. Continuous Mode
USB Virtual Port
Manual Mode
Enable Sleep Function
Disable Sleep Function
