Barcode Scanner Module User Manual

2 / 57 Rev1.0 Date:180621

SPECIFICATIONS

Operating voltage

Operating current

135mA

Standby current

58mA

Sleep current

2mA

Operating temperature

0℃~60℃

Operating Humidity

5%~95%(Non-condensing)

Interfaces

UART、USB

Light source

White

Scan angle

Tilt 360°， Skew ±65°，Pitch ±60°

FOV

28°(Horizontal)，21.5°(Vertical)

Dimension

53.3mm × 21.4mm
