Waveshare Barcode Scanner Module User Manual

Barcode Scanner Module User Manual
17 / 57 Rev1.0 Date:180621
Image stabilization time
It is the time for module to stabilizing image if brightness changed is detected in
sensing mode. The range is 0~25.5s, and 0.4s by default.
4. Command Mode
In command mode, scanner will begin scanning after receive the command from
MCU. (That is set bit0 to 1 on address 0x0002).
No Interval
500ms
*1000ms
1500ms
2000ms
100ms
*400ms
1000ms
2000ms
Command Mode
