Barcode Scanner Module User Manual
43
/
57
Rev1.0 Date:180621
17.
M
SI
Enable/Disable scann
ing MSI code
Setting the min scan
nable length of MS
I:
Setting the max scann
able length of MS
I:
18.
R
SS
Enable/Disable scann
ing RSS
-
14
Enable Scan
ning MSI
*D
isable S
cannig MS
I
MSI Min Length 0
*MSI Min Len
gth 4
* MSI Max Length
32
MSI Max Length
255
Enable Scannin
g RSS-
14
*D
isable Sc
anning RSS-
14
