114 CHAPTER 10 CLICK 112/114
S4: Input Mapping
1 2 3 4 Channel
O O O O Software mode
O O O On 1–2
O O On O 3–4
O O On On 5–6
O On O O 7–8
O On O On 9–10
O On On O 11–12
O On On On 13–14
On O O O 15–16
On O O On 17–18
On O On O 19–20
On O On On 21–22
On On O O 23–24
On On O On 25–26
On On On O 27–28
Table 10.3 – Click 112 DIP Switch Channel Input Map Settings
S4: Input Mapping
1 2 3 4 Channel
O O O O Software mode
O O O On 1–4
O O On O 5–8
O O On On 9–12
O On O O 13–16
O On O On 17–20
O On On O 21–24
O On On On 25–28
Table 10.4 – Click 114 DIP Switch Channel Input Map Settings
If any switch is on (up), Hardware mode is selected, meaning the inputs can only be mapped
using the DIP switches (as shown in the tables above), and Click Supervisor and the front
panel menu will be able to display the current setting, but not change it. If all switches are
o (down), Soware mode is selected and Click Supervisor and the front panel menu will
be able to both display and change the current setting.
