154 CHAPTER 14  CLICK 201/202/204

Figure 14.4 – Wiring DC Power out of the Click 201/202/204

Note

Do not wire out of the DC OK terminal; it supplies only 20 mA and should only be used

to monitor the status of the power supply.
