CHAPTER 23 CLICK 301 197
Figure 23.9 – Expert Driver Autobaud Tab
Setting Description
Command
Allows you to set the command sent from the device during the
autobaud process. Don’t change these values unless instructed to by
Wavetronix Technical Services.
Response
Shows the response the device is expecting from the above command.
Don’t change these values unless instructed to by Wavetronix Technical
Services.
SmartSensor ID
Shows the ID number of the sensor with which the Click device is
currently communicating. This only shows the number after you have
autobauded the Click device; when the Click device is not communicat-
ing with a sensor, this option will display a 1.
Server/Client
Allows you to set whether the device is a server or client. (This option is
not related to device autobauding.)
Table 23.7 – Expert Driver Autobaud Tab
e Ethernet > General > Network tab allows you to congure network settings (see Fig-
ure 23.10 and Table 23.8).
